The system Inmarsat-C/mini-C is the digital storage store-and-forward messaging, as well as telemetry applications and tracking



The system Inmarsat-C/mini-C is the digital storage store-and-forward messaging, as well as telemetry applications and tracking. The system is universally recognized by the International Maritime Organization (IMO) as a system of safety of life and property at sea, meeting the requirements of the Global Maritime Distress and Safety System (GMDSS), through which have been established internationally the procedures, the equipment and the communication protocols in order to increase safety and to facilitate the rescue of vessels, boats and airplanes.

Advantages Inmarsat-C & mini-C

  • Full compliance with the latest SOLAS / GMDSS standards of Inmarsat-C with the alarm message to meet the CN114, IEC 1097-4, IEC 945 and the EU specifications
  • Full compliance with the latest Inmarsat-C (mini-C) standards
  • Two-way data exchange, fax and e-mail, with global coverage
  • Polling and position reporting
  • Programming of DNID for worldwide coverage
  • Ship Security Alert System (SSAS) functions
  • Full coverage of LRIT (Long-Range Identification and Tracking) specifications and system requirements.
  • Ability to receive the transmitted Inmarsat-C messages for navigation safety (mini-C).
  • Extremely small, lightweight, and durable terminal
  • Easy to install terminal
  • Distress transmission risk signal in Rescue Coordination Centers
  • Fixed to Mobile Data for registered users to networks PSTN, Telex, PSDN
  • Inmarsat-C/mini-C to e-mail two-way messaging of mobile-land and land-mobile for registered users
  • Mobile-land data reporting with:
    • the ability to plan in advance of DNID for storing reports on them and export from their user / company
    • send reports to e-mail or IP address
  • Enhanced Group Call (EGC)
    • SafetyNET for maritime safety information broadcast
    • FleetNET for information broadcast of commercial interest in selected terminals belonging to a 'closed user group'
  • Polling with or without text
  • Call Confirmation (PDN) & Message Status for status monitoring message

Inmarsat-C & mini-C terminal systems of Cobham depending on their certification are:

SAILOR 6110 mini-C GMDSS
SAILOR 6120 mini-C SSAS
SAILOR 6130 mini-C LRIT
SAILOR 6140 mini-C Maritime
SAILOR 6150 mini-C Distress
